Whirlpool Refrigerator Condenser Fan W11505535 W10909387 W10527155 W11127829 (Open box)

Whirlpool Refrigerator Condenser Fan W11505535 W10909387 W10527155 W11127829 (Open box).

Whirlpool Refrigerator Condenser Fan Motor W11505535

Genuine OEM Refrigerator Machine Compartment Condenser Blower Fan Motor Assembly

📝 Product Overview

The Whirlpool W11505535 is a factory-original replacement condenser fan motor assembly. Positioned in the lower rear machine compartment next to the compressor on select French door, side-by-side, and bottom-freezer refrigerators, this genuine OEM part drives the fan blade that pulls ambient air across the condenser coils and compressor body.

As an Authentic Whirlpool Component , this heavy-duty motor plays a vital role in thermal heat dissipation. By drawing heat away from the hot refrigerant tubing, it enables efficient gas condensation, prevents compressor overheating, and maintains overall refrigeration efficiency. Choosing a genuine factory replacement motor guarantees exact wiring plug connector orientation, precise mounting bracket alignment, and smooth, whisper-quiet motor operation.

🔍 Signs Your Refrigerator Condenser Fan Motor Needs Replacement

• Refrigerator Warm in Both Sections: The compressor runs continuously or trips on its thermal overload protector because heat cannot escape the condenser coils, causing cabinet temperatures to rise.
• Loud Rattling, Humming, or Squealing from Lower Back: Worn internal sleeve bearings, motor shaft play, or debris hitting fan blades produce harsh mechanical noises at the bottom rear of the refrigerator.
• Compressor Abnormally Hot to the Touch or Clicking: Without active airflow from the fan, the compressor overheats and rapidly clicks on and off via its overload relay.
• Motor Shaft Seized or Fails to Spin: Shorted motor windings or locked bearings prevent the fan blade from rotating when power is applied.

🔧 Technical Specifications

• Part Number: W11505535 (Replaces W10909387, W10527155, W11127829, AP6989688, PS16218956)
• Part Type: Refrigerator Lower Machine Compartment Condenser Blower Fan Motor
• Function: Condenser Coil Heat Dissipation & Compressor Cooling
• Condition: Brand New, Genuine Whirlpool OEM Replacement Part
• Brand Compatibility: Precision engineered to fit select Whirlpool, KitchenAid, Maytag, Jenn-Air, and Amana refrigerators.

📦 Professional Installation, Care & Maintenance Tips

⚠️ CRITICAL SAFETY WARNING: ELECTRICAL ISOLATION REQUIRED! Replacing a condenser fan motor involves working directly inside the lower machine compartment near line-voltage wiring, high-temperature copper tubing, and electrical components. **Always completely disconnect electrical power by unplugging the refrigerator power cord or tripping the main breaker before starting service**. Wear heavy-duty cut-resistant mechanics gloves and safety glasses. Pro Tip: Vacuum Condenser Coils & Hand-Drive Screws! Accessing the condenser fan motor requires pulling the refrigerator away from the wall and removing the lower rear cardboard or metal access panel. **Take clear smartphone reference photos of wiring harness routing, grounding clips, and fan blade placement on the motor shaft before unhooking anything**. While the rear panel is off, take the opportunity to vacuum and brush away dust and pet hair from the condenser coils to maximize airflow efficiency. Transfer the fan blade and any rubber vibration dampeners onto your new **Whirlpool W11505535** motor shaft, ensuring the blade is pressed onto the shaft to the exact depth noted prior. When securing the motor bracket to the chassis, **always hand-tighten mounting screws using standard hand tools**—over-tightening with power drivers can strip sheet-metal mounting holes or crack bracket tabs. Installation Steps: Isolate electrical power to the appliance. Pull the refrigerator away from the wall and unbolt the rear lower access panel. Take reference photos of wire harness routing and fan blade depth. Disconnect the wiring harness connector, unbolt the fan motor mounting bracket, and remove the assembly. Transfer the fan blade and rubber isolators onto your new genuine **Whirlpool W11505535** condenser fan motor, mount it back onto the chassis bracket, hand-tighten securing screws, reconnect the wire harness, reinstall the rear cover panel, restore electrical power, and verify smooth airflow across the coils.

Specifications

• Type: Condensor Fan Assembly

Condition: Open box
